Specification
Item STC3MA03
3pf		 STC3MA06
6pf		 STC3MB10
10pf		 STC3MD20
20pf		 STC3ME30
30pf
Black Blue Ivory Pink Green
Model

Capacitance

(pF Min)

 1.5 max 2.0 max 3.0 max 5.8 max 8.0 max

Capacitance

(pF Max)
3.0
+30 −0
%
6.0
+30 −0
%
10.0
+30 −0
%
20.0
+30 −0
%
28.5
+30 −0
%

Capacitance Drift

(Max)

 ± 3% ± 3% ± 3% ± 3% ± 3%

Temperature Coefficient

( ppm / ℃ )

 NP0±300 NP0±300 N750±400 N1300±400 N1300±400
Q Value
(at 1 MHz, C max )		 300 Min 500 Min 500 Min 200 Min 200 Min
Insulation Resistance 104MΩMin 104MΩMin 104MΩMin 104MΩMin 104MΩMin
DC Rated Voltage 100 VDC 100 VDC 100 VDC 100 VDC 100 VDC
DC Withstanding Voltage 220 VDC 220 VDC 220 VDC 220 VDC 220 VDC

REACH(SVHC)

 List 241 completed List 241 completed List 241 completed List 241 completed List 241 completed
Operation Temperature -25℃ to 85℃ -25℃ to 85℃ -25℃ to 85℃ -25℃ to 85℃ -25℃ to 85℃
Rotation Torque 15 ~ 72 gf.cm 15 ~ 72 gf.cm 15 ~ 72 gf.cm 15 ~ 72 gf.cm 15 ~ 72 gf.cm
